NHN Insulating Paper
Products Description NMNInsulation paper has a three-layer structure, which is composed of imported Nomex paper + polyester film + Nomex paper. It has good insulation and oil resistance, and is very suitable for use in oil-immersed transformers. Product thickness: 0.15mm, 0.18mm, 0.23mm,...
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Products Description
NHNInsulation paper has a three-layer structure, which is composed of imported Nomex paper + Polyimide film + Nomex paper. It has good insulation and oil resistance, and is very suitable for use in oil-immersed transformers.
Product thickness: 0.15mm, 0.18mm, 0.23mm, 0.25mm......0.5mm
Heat resistance level: customized according to customer needs (the temperature resistance of the product depends on the thickness of the intermediate film. Customers can contact our sales, who will give you professional advice)
Minimum order quantity: 1 roll (100KG), this order is a sample order, we can provide free samples (1-10 kg), but the freight needs to be borne by the customer
Product certificate: We provide SGS third-party inspection certificate
Product production video: We provide a full process video of the production of NHN insulation paper in the workshop, which can be sent directly to customers
Monthly production capacity: 1,000 tons
Production lines: 3
Product quality inspection process: 8 to quality inspection procedures, each process requires the confirmation and signature of the person in charge, and the product quality is guaranteed
| NO. | Item | Unit | Index | ||||
| 1 | Nominal thickness | mm | 0.15 | 0.20 | 0.25 | ||
| 2 | Tensile strength | Longitudinal | Non-bending | N/10mm | ≥120 | ≥160 | ≥200 |
| After bending | ≥70 | ≥90 | ≥150 | ||||
| Horizontal | Non-bending | ≥80 | ≥100 | ≥120 | |||
| After bending | ≥50 | ≥80 | ≥100 | ||||
| 3 | Elongation | Longitudinal | Non-bending | % | ≥10 | ||
| Horizontal | Non-bending | ≥8 | |||||
| 4 | Breakdown voltage | Non-bending | KV | ≥7 | ≥11 | ≥13 | |
| After bending | ≥6 | ≥9 | ≥12 | ||||
| 5 | Normal adhesion | 一 | No stratification | ||||
| 6 | Thermal adhesion(200±2C10min) | - | No delamination,no blister,no glue flow | ||||
| 7 | Long-term heat resistance index,temperatureindex(TI) | ℃ | ≥180 | ||||
| 8 | Storage life | Month | 12 | ||||
Special-shaped processing
NHN In addition to providing each roll form, we can also process it into insulating parts (such as winding protection insulation parts) according to customer drawings.
industry applications
Interlayer insulation
Filling insulation
Interlayer insulation
Protective padding
why choose us?
1/We provide a variety of customized services, including paper thickness, temperature resistance, raw materials, slitting width, weight of each roll, and AB grade of the product.
2/We provide the best service attitude. Pre-sales provide you with a quotation. The technical team in the sales process customizes the appropriate product according to your needs. The after-sales team is at your service at any time within one year.
3/We provide a third-party SGS test report and a product quality inspection form for each batch. We provide the best quality products to customers.
FAQ
1/Q:I don't see my designed dimensions/packaging/delivery etc. Can you make a special order for us?
A:Sure. We're truly customized. You're free to tell us whatever you want.
2/Q:Do you deal with urgent orders?
A:Sure. Please contact ASAP for details.
3/Q:I bought from you once. Can I have a special offer this time?
A:Contact for details. We do value our customers; we can and will offer you good price.
